Remote operation of the transceiver is possible with the optional SCU-LAN10 and SCU-LAN10 Network Remote Control Software. Remote Operation with optional LAN unit (SCU-LAN10)
MPVD (Multi-Purpose VFO Outer Dial), is a large multi-purpose ring around the outside of the VFO dial that enables control of Clarifier, C/S (custom selection function) and recall of memory channels. Similar to the FTDX101 series, the MULTI display, RX operation status display, Center, FIX and Cursor modes are available.įront Panel Designed for Superior Operating Efficiency Frequency setting and adjustment can also be performed by turning the MAIN dial or touching the scope display.
By touching the frequency display, the numeric keypad is displayed, and the active band and frequency adjustment can be set by direct input. The 5-inch Full-Color panel shows the 3DSS display. Thanks to its characteristics that improve the C/N (carrier to noise) ratio and the careful selection of components in the design, the phase noise characteristic of the local signal achieves an excellent value of -145dB or less in 14MHz at 2kHz separation.ģDSS (3-Dimensional Spectrum Stream) on the 5-inch Full-Color TFT Display with Touch-Panel Functionality The local circuit of the new FTDX10 uses 250MHz HRDDS method same as the FTDX101 series. Thanks to the Narrow Band SDR with the latest circuit configuration including 500Hz, 3kHz and 12kHz roofing filters and low-noise oscillator, the RMDR (Reciprocal Mixing Dynamic Range) reaches 116dB or more, the close-in BDR (Blocking Dynamic Range) reaches 141dB or more and 3rd IMDR (third-order Intermodulation Dynamic Range) reaches 109dB or more in the 14MHz band at 2kHz separation.Ģ50MHz HRDDS (High Resolution Direct Digital Synthesizer) affords Quiet and Clear Reception It makes it possible to incorporate excellent narrow bandwidth crystal roofing filters that have the desired sharp “cliff edge” shape factor. Like the FTDX101 series, the Down Conversion type receiver configuration with the first IF at 9MHz has been adopted. Narrow Band SDR with 3 types of Roofing Filters and Phenomenal Multi-signal receiving Characteristics The Narrow band SDR receiver emphasizes excellent receiver performance, while the Direct Sampling SDR provides a Digital Processing Real-Time Spectrum Scope. Like the FTDX101 series, the new FTDX10 utilizes the Yaesu Hybrid SDR configuration - Narrow Band SDR and Direct Sampling SDR. We are pleased to introduce the FTDX10, a new long-awaited compact HF/50MHz 100W SDR Transceiver!
